That's nice !! Here is the Alarm driver.
The driver needs to be updated for changes on how the new httpPost works but as long as you don't use a username/password in the app or webserver for it then you be will ok.
/**
*
* Shelly Alarm Driver
*
* Copyright © 2019 Scott Grayban
*
* Please Note: This app is NOT released under any open-source license.
* Please be sure to read the license agreement before installing this code.
*
* This software package is created and licensed by Scott Grayban.
*
* This software, along with associated elements, including but not limited to online and/or electronic documentation are
* protected by international laws and treaties governing intellectual property rights.
*
* This software has been licensed to you. All rights are reserved. You may use and/or modify the software.
* You may not sublicense or distribute this software or any modifications to third parties in any way.
*
* You may not distribute any part of this software without the author's express permission
*
* By downloading, installing, and/or executing this software you hereby agree to the terms and conditions set forth
* in the Software license agreement.
* This agreement can be found on-line at: https://sgrayban.github.io/Hubitat-Public/software_License_Agreement.txt
*
* Hubitat is the Trademark and intellectual Property of Hubitat Inc.
* Shelly is the Trademark and Intellectual Property of Allterco Robotics Ltd
* Scott Grayban has no formal or informal affiliations or relationships with Hubitat or Allterco Robotics Ltd.
*
* Unless required by applicable law or agreed to in writing, software distributed under the License is distributed
* on an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License Agreement
* for the specific language governing permissions and limitations under the License.
*
*-------------------------------------------------------------------------------------------------------------------
*
* See all the Shelly Products at https://shelly.cloud/
*
* Shelly Alarm works off a Shelly 1 or Shelly 1PM
* It is based on the project by Jason Churchward --> http://blog.smarterhome.club/2019/09/07/shelly1strobealarm/
*
* Changes:
* 1.0.1 - Added code that will allow you to upgrade the device firmware and will auto-refresh in 30 seconds.
* 1.0.0 - Initial port of Shelly Alarm
*
*/
import groovy.json.*
import groovy.transform.Field
metadata {
definition (
name: "Shelly Alarm",
namespace: "sgrayban",
author: "Scott Grayban"
)
{
capability "Actuator"
capability "Sensor"
capability "Refresh"
capability "Switch"
capability "Polling"
capability "Alarm"
attribute "switch", "string"
attribute "FW_Update_Needed", "string"
attribute "LastRefresh", "string"
attribute "internal_tempC", "string"
attribute "MAC", "string"
attribute "Primary_IP", "string"
attribute "Primary_SSID", "string"
attribute "Cloud", "string"
attribute "Cloud_Connected", "string"
attribute "alarm", "string"
attribute "status", "string"
attribute "WiFiSignal", "string"
attribute "Secondary_IP", "string"
attribute "Secondary_SSID", "string"
attribute "DeviceType", "string"
command "RebootDevice"
command "UpdateDeviceFW" // ota?update=1
}
preferences {
def refreshRate = [:]
refreshRate << ["1 min" : "Refresh every minute"]
refreshRate << ["5 min" : "Refresh every 5 minutes"]
refreshRate << ["15 min" : "Refresh every 15 minutes"]
refreshRate << ["30 min" : "Refresh every 30 minutes"]
input("ip", "string", title:"IP", description:"Shelly IP Address", defaultValue:"" , required: false, displayDuringSetup: true)
input name: "username", type: "text", title: "Username:", description: "(blank if none)", required: false
input name: "password", type: "password", title: "Password:", description: "(blank if none)", required: false
input ("refresh_Rate", "enum", title: "Device Refresh Rate", options: refreshRate, defaultValue: "30 min")
input "locale", "enum", title: "Choose refresh date format", required: true, defaultValue: true, options: [US:"US MM/DD/YYYY",UK:"UK DD/MM/YYYY"]
input name: "debugOutput", type: "bool", title: "Enable debug logging?", defaultValue: true
input name: "debugParse", type: "bool", title: "Enable JSON parse logging?", defaultValue: false
input name: "txtEnable", type: "bool", title: "Enable descriptionText logging", defaultValue: true
input name: "Shellyinfo", type: "text", title: "<center><font color=blue>Info Box</font><br>Shelly API docs are located</center>",
description: "<center><br><a href='http://shelly-api-docs.shelly.cloud/' title='shelly-api-docs.shelly.cloud' target='_blank'>[here]</a></center>",
required: false
input name: "Donate", type: "text", title: "<center><font color=blue>Donate</font><br>If you like my drivers please donate</center>",
description: "<center><a href='https://paypal.me/sgrayban'>[here]</a></center>", required: false
}
}
def initialize() {
log.info "initialize"
}
def installed() {
log.debug "Installed"
}
def uninstalled() {
log.debug "Uninstalled"
unschedule()
}
def setVersion(){
state.Version = "1.0.1"
state.InternalName = "ShellyAlarm"
}
def updated() {
if (txtEnable) log.info "Preferences updated..."
log.warn "Debug logging is: ${debugOutput == true}"
unschedule()
dbCleanUp()
switch(refresh_Rate) {
case "1 min" :
runEvery1Minute(autorefresh)
break
case "5 min" :
runEvery5Minutes(autorefresh)
break
case "15 min" :
runEvery15Minutes(autorefresh)
break
default:
runEvery30Minutes(autorefresh)
}
if (txtEnable) log.info ("Auto Refresh set for every ${refresh_Rate} minute(s).")
if (debugOutput) runIn(1800,logsOff)
state.LastRefresh = new Date().format("YYYY/MM/dd \n HH:mm:ss", location.timeZone)
version()
getSettings()
refresh()
}
private dbCleanUp() {
state.remove("version")
state.remove("Version")
state.remove("ShellyfwUpdate")
state.remove("power")
state.remove("overpower")
state.remove("dcpower")
state.remove("max_power")
state.remove("internal_tempC")
}
// We dont use this anymore
// but it's still called so
// keep it until I fix the
// http POST calls.
def parse(description) {
return
}
def refresh(){
getSettings()
logDebug "Shelly Status called"
def params = [uri: "http://${username}:${password}@${ip}/status"]
try {
httpGet(params) {
resp -> resp.headers.each {
logJSON "Response: ${it.name} : ${it.value}"
}
obs = resp.data
if(logSet == false){
logJSON "params: ${params}"
logJSON "response contentType: ${resp.contentType}"
logJSON "response data: ${resp.data}"
}
if (obs.temperature != null) sendEvent(name: "internal_tempC", value: obs.temperature)
if (obs.overtemperature != null) sendEvent(name: "DeviceOverTemp", value: obs.overtemperature)
ison = obs.relays.ison[0]
if (ison == true) {
sendEvent(name: "switch", value: "on")
sendEvent(name: "status", value: "on")
sendEvent(name: "alarm", value: "on")
} else {
sendEvent(name: "switch", value: "off")
sendEvent(name: "status", value: "off")
sendEvent(name: "alarm", value: "off")
}
if (obs.wifi_sta != null) {
state.rssi = obs.wifi_sta.rssi
state.ssid = obs.wifi_sta.ssid
state.ip = obs.wifi_sta.ip
sendEvent(name: "Primary_SSID", value: state.ssid)
sendEvent(name: "Primary_IP", value: state.ip)
}
state.mac = obs.mac
sendEvent(name: "MAC", value: state.mac)
/*
-30 dBm Excellent | -67 dBm Good | -70 dBm Poor | -80 dBm Weak | -90 dBm Dead
*/
signal = state.rssi
if (signal <= 0 && signal >= -70) {
sendEvent(name: "WiFiSignal", value: "<font color='green'>Excellent</font>", isStateChange: true);
} else
if (signal < -70 && signal >= -80) {
sendEvent(name: "WiFiSignal", value: "<font color='green'>Good</font>", isStateChange: true);
} else
if (signal < -80 && signal >= -90) {
sendEvent(name: "WiFiSignal", value: "<font color='yellow'>Poor</font>", isStateChange: true);
} else
if (signal < -90 && signal >= -100) {
sendEvent(name: "WiFiSignal", value: "<font color='red'>Weak</font>", isStateChange: true);
}
// Device FW Updates
state.has_update = obs.has_update
if (state.has_update == true) {
if (txtEnable) log.info "sendEvent NEW SHELLY FIRMWARE"
sendEvent(name: "FW_Update_Needed", value: "<font color='red'>FIRMWARE Update Required</font>")
}
if (state.has_update == false) {
if (txtEnable) log.info "sendEvent Device FW is current"
sendEvent(name: "FW_Update_Needed", value: "<font color='green'>Device FW is current</font>")
}
// Cloud
state.cloud = obs.cloud.enabled
if (state.cloud == true) {
sendEvent(name: "Cloud", value: "<font color='green'>Enabled</font>")
} else {
sendEvent(name: "Cloud", value: "<font color='red'>Disabled</font>")
}
state.cloudConnected = obs.cloud.connected
if (state.cloudConnected == true) {
sendEvent(name: "Cloud_Connected", value: "<font color='green'>Enabled</font>")
} else {
sendEvent(name: "Cloud_Connected", value: "<font color='red'>Not Connected</font>")
}
} // End try
} catch (e) {
log.error "something went wrong: $e"
}
} // End Refresh Status
// Get shelly device type
def getSettings(){
logDebug "Get Shelly Settings"
def paramsSettings = [uri: "http://${username}:${password}@${ip}/settings"]
try {
httpGet(paramsSettings) {
respSettings -> respSettings.headers.each {
logJSON "ResponseSettings: ${it.name} : ${it.value}"
}
obsSettings = respSettings.data
logJSON "params: ${paramsSettings}"
logJSON "response contentType: ${respSettings.contentType}"
logJSON "response data: ${respSettings.data}"
state.DeviceType = obsSettings.device.type
if (state.DeviceType == "SHSW-1") sendEvent(name: "DeviceType", value: "Shelly 1")
if (state.DeviceType == "SHSW-PM") sendEvent(name: "DeviceType", value: "Shelly 1PM")
if (state.DeviceType == "SHSW-21") sendEvent(name: "DeviceType", value: "Shelly 2")
if (state.DeviceType == "SHSW-25") sendEvent(name: "DeviceType", value: "Shelly 2.5")
if (state.DeviceType == "SHSW-44") sendEvent(name: "DeviceType", value: "Shelly 4Pro")
if (state.DeviceType == "SHEM") sendEvent(name: "DeviceType", value: "Shelly EM")
if (state.DeviceType == "SHPLG-1") sendEvent(name: "DeviceType", value: "Shelly Plug")
if (state.DeviceType == "SHPLG-S") sendEvent(name: "DeviceType", value: "Shelly PlugS")
updateDataValue("model", state.DeviceType)
updateDataValue("ShellyHostname", state.ShellyHostname)
updateDataValue("ShellyIP", obsSettings.wifi_sta.ip)
updateDataValue("ShellySSID", obsSettings.wifi_sta.ssid)
updateDataValue("manufacturer", "Allterco Robotics")
updateDataValue("MAC", state.mac)
if (obsSettings.wifi_sta1 != null) {
state.rssi = obsSettings.wifi_sta1.rssi
state.Secondary_ssid = obsSettings.wifi_sta1.ssid
state.Secondary_IP = obsSettings.wifi_sta1.ip
if (obsSettings.wifi_sta1.enabled == true) sendEvent(name: "Secondary_SSID", value: state.Secondary_ssid)
if (state.Secondary_IP != null) sendEvent(name: "Secondary_IP", value: state.Secondary_IP)
sendEvent(name: "WiFiSignal", value: state.rssi)
}
state.ShellyHostname = obsSettings.device.hostname
} // End try
} catch (e) {
log.error "something went wrong: $e"
}
} // End Refresh Status
//Alarm on
def on() {
logDebug "Executing switch.on"
sendSwitchCommand "turn=on"
}
def strobe() {
logDebug "Executing strobe"
on()
}
def both() {
logDebug "Executing strobe"
on()
}
def siren() {
logDebug "Executing strobe"
on()
}
//Alarm off
def off() {
logDebug "Executing switch.off"
sendSwitchCommand "turn=off"
}
def ping() {
logDebug "ping"
poll()
}
def logsOff(){
log.warn "debug logging auto disabled..."
device.updateSetting("debugOutput",[value:"false",type:"bool"])
}
def autorefresh() {
if (locale == "UK") {
logDebug "Get last UK Date DD/MM/YYYY"
state.LastRefresh = new Date().format("d/MM/YYYY \n HH:mm:ss", location.timeZone)
sendEvent(name: "LastRefresh", value: state.LastRefresh, descriptionText: "Last refresh performed")
}
if (locale == "US") {
logDebug "Get last US Date MM/DD/YYYY"
state.LastRefresh = new Date().format("MM/d/YYYY \n HH:mm:ss", location.timeZone)
sendEvent(name: "LastRefresh", value: state.LastRefresh, descriptionText: "Last refresh performed")
}
if (txtEnable) log.info "Executing 'auto refresh'" //RK
refresh()
}
private logJSON(msg) {
if (settings?.debugParse || settings?.debugParse == null) {
log.info "$msg"
}
}
private logDebug(msg) {
if (settings?.debugOutput || settings?.debugOutput == null) {
log.debug "$msg"
}
}
// handle commands
//RK Updated to include last refreshed
def poll() {
if (locale == "UK") {
logDebug "Get last UK Date DD/MM/YYYY"
state.LastRefresh = new Date().format("d/MM/YYYY \n HH:mm:ss", location.timeZone)
sendEvent(name: "LastRefresh", value: state.LastRefresh, descriptionText: "Last refresh performed")
}
if (locale == "US") {
logDebug "Get last US Date MM/DD/YYYY"
state.LastRefresh = new Date().format("MM/d/YYYY \n HH:mm:ss", location.timeZone)
sendEvent(name: "LastRefresh", value: state.LastRefresh, descriptionText: "Last refresh performed")
}
if (txtEnable) log.info "Executing 'poll'" //RK
refresh()
}
def sendSwitchCommand(action) {
if (txtEnable) log.info "Calling /relay/ with $action"
if (username != null) {
host = "${username}:${password}@${ip}"
} else {
host = "${ip}"
}
sendHubCommand(new hubitat.device.HubAction (
method: "POST",
path: "/relay/0",
body: action,
headers: [HOST: host, "Content-Type": "application/x-www-form-urlencoded"]
))
runIn(1, refresh)
}
def RebootDevice() {
if (txtEnable) log.info "Rebooting Device"
if (username != null) {
host = "${username}:${password}@${ip}"
} else {
host = "${ip}"
}
sendHubCommand(new hubitat.device.HubAction(
method: "POST",
path: "/reboot",
body: action,
headers: [HOST: host, "Content-Type": "application/x-www-form-urlencoded"]
))
runIn(10,refresh)
}
def UpdateDeviceFW() {
if (txtEnable) log.info "Updating Device FW"
if (username != null) {
host = "${username}:${password}@${ip}"
} else {
host = "${ip}"
}
sendEvent(name: "FW_Update_Needed", value: "Please Wait..Updating FW.")
sendHubCommand(new hubitat.device.HubAction(
method: "POST",
path: "/ota?update=1",
body: action,
headers: [
HOST: host,
"Content-Type": "application/x-www-form-urlencoded"
]
))
runIn(30,refresh)
}
def version(){
updatecheck()
schedule("0 0 18 1/1 * ? *", updatecheck) // Cron schedule
// schedule("0 0/1 * 1/1 * ? *", updatecheck) // Test Cron schedule
}
def updatecheck(){
setVersion()
def paramsUD = [uri: "http://sgrayban.borgnet.online:8081/scotts-projects/version.json"]
try {
httpGet(paramsUD) { respUD ->
if (debugParse) log.warn " Version Checking - Response Data: ${respUD.data}" // Troubleshooting Debug Code - Uncommenting this line should show the JSON response from your webserver
def copyrightRead = (respUD.data.copyright)
state.Copyright = copyrightRead
def newVerRaw = (respUD.data.versions.Driver.(state.InternalName))
def newVer = (respUD.data.versions.Driver.(state.InternalName).replace(".", ""))
def currentVer = state.Version.replace(".", "")
state.UpdateInfo = (respUD.data.versions.UpdateInfo.Driver.(state.InternalName))
state.author = (respUD.data.author)
if(newVer == "NLS"){
state.DriverStatus = "<b>** This driver is no longer supported by $state.author **</b>"
log.warn "** This driver is no longer supported by $state.author **"
}
else if(newVer == "BETA"){
state.Status = "<b>** THIS IS BETA CODE **</b>"
log.warn "** BETA CODE **"
}
else if(currentVer < newVer){
state.DriverStatus = "<b>New Version Available (Version: $newVerRaw)</b>"
log.warn "** There is a newer version of this driver available (Version: $newVerRaw) **"
log.warn "** $state.UpdateInfo **"
}
else if(currentVer > newVer){
state.DriverStatus = "<b>You are using a Test version of this Driver (Version: $newVerRaw)</b>"
}
else{
state.DriverStatus = "Current"
log.info "You are using the current version of this driver"
}
} // httpGet
} // try
catch (e) {
log.error "Something went wrong: CHECK THE JSON FILE AND IT'S URI - $e"
}
if(state.DriverStatus == "Current"){
state.UpdateInfo = "Up to date"
sendEvent(name: "DriverUpdate", value: state.UpdateInfo)
sendEvent(name: "DriverStatus", value: state.DriverStatus)
}
else {
sendEvent(name: "DriverUpdate", value: state.UpdateInfo)
sendEvent(name: "DriverStatus", value: state.DriverStatus)
}
sendEvent(name: "DriverAuthor", value: "sgrayban")
sendEvent(name: "DriverVersion", value: state.Version)
}
. I'd imagine it should be possible.
